WardFlex 15C.WF250 Corrugated Tubing, 1/2 in, 250 ft L, Stainless Steel
- Manufacturer: ASC Engineered Solutions
- Brand Name: WardFlex
- Part#: WAR12250WFMAX
- MPN: 15C.WF250
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at All Branches
-
Price:
WARDFlex® MAX is a corrugated stainless steel tubing (CSST) system designed to distribute fuel gas in residential housing units and commercial structures. WARDFlex® MAX has been engineered, tested and certified to meet the performance requirements of American National Standard for fuel gas systems using corrugated stainless steel tubing, ANSI LC-1. As such is acceptable for use with all recognized fuel gases, including natural gas and propane.
WardFlex Corrugated Tubing, 1/2 in Connection, 0.81 in Outside Diameter, 250 ft Length, 25 psi Working Pressure, -40 to 165 deg F, Stainless Steel, Material Standard: ASTM A2408, E84, Polyethylene Jacket, Black
| Color | : | Black |
| Connection Size | : | 1/2 in |
| Jacket Material | : | Polyethylene |
| Length | : | 250 ft |
| Material Standard | : | ASTM A2408, E84 |
| Material | : | Stainless Steel |
| Outside Diameter | : | 0.81 in |
| Temperature Rating | : | -40 to 165 deg F |
| Working Pressure | : | 25 psi |
- Wide range of tubing sizes and coil lengths
- Double annealing for maximum flexibility
- Continuous run coils
- Helium and vacuum tested
- Quick and easy installation
- Lightweight and flexible
- Fewer fittings
- Conductive polyethylene jacket
- UV inhibitors
- Coating marked every 2 ft
- 100% leak tested
