Rinnai® I Series i120SN Condensing Gas Fired Combo Boiler, 95.5 % AFUE, 15000 to 120000 Btu/hr BTU, 0.88 gal Capacity
- Manufacturer: Rinnai Corporation
- Brand Name: Rinnai®
- Part#: RINI120SN
- MPN: i120SN
- UPC: 766156012488
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at All Branches
-
Price:
The I Series i120SN model features Rinnai® exclusive self-cleaning stainless steel heat exchanger coupled with a secondary flat plate heat exchanger. This heat only model can deliver whole house heating to enhance your comfort. The i120SN provides an input rating of 120 KBtu/hr. Fueled with either natural gas or propane this Rinnai® condensing gas boiler has obtained one of the highest AFUEs (annual fuel utilization efficiency) in the industry. Plus, the compact wall-mounted design saves space over traditional boilers.
Rinnai® Condensing Gas Fired Combo Boiler, I Series, 120 V, 6 A, 50 W Power, 60 Hz Frequency, 95.5 % AFUE, 15000 to 120000 Btu/hr BTU, 0.88 gal Capacity, 13 to 45 psi Pressure, Natural Gas Fuel, Direct Vent, Modulating Burner, 10 A Fuse, Ignition System: Direct Electronic, Noise Rating: 40 dBA, 10.9 sq-ft Area, Wall Mounting, 104 to 180 deg F, Dimensions: 26.4 in H x 18.5 in W x 10.9 in D, Additional Information: 112000 Btu/hr Heating Capacity, Ultra Low Nox
| AFUE Rating | : | 95.5 % |
| Additional Information | : | 112000 Btu/hr Heating Capacity, Ultra Low Nox |
| Amperage Rating | : | 6 A |
| Area | : | 10.9 sq-ft |
| BTU Rating | : | 15000 to 120000 Btu/hr |
| Burner Type | : | Modulating |
| Capacity | : | 0.88 gal |
| Dimensions | : | 26.4 in H x 18.5 in W x 10.9 in D |
| Frequency Rating | : | 60 Hz |
| Fuel Type | : | Natural Gas |
| Fuse Rating | : | 10 A |
| Ignition System | : | Direct Electronic |
| Mounting Type | : | Wall |
| Noise Rating | : | 40 dBA |
| Power Rating | : | 50 W |
| Pressure Rating | : | 13 to 45 psi |
| Product Depth | : | 10.9 in / (276 mm) |
| Product Height | : | 26.4 in / (671 mm) |
| Product Sub Series | : | I-Series |
| Product Weight | : | 62.0 lb / (28 kg) |
| Product Width | : | 18.5 in / (471 mm) |
| Series | : | I Series |
| Temperature Rating | : | 104 to 180 deg F |
| Vent Type | : | Direct |
| Voltage Rating | : | 120 V |
| Warranty - Standard for Commercial | : | 5 yrs on Heat Exchanger/ 5 years on Parts/ 1 Year on Labor |
| Warranty - Standard for Residential | : | 12 yrs on Heat Exchanger/ 5 years on Parts/ 1 Year on Labor |
- Outdoor reset control system with sensor
- Modulating wire mesh burner
- Stainless steel water tube condensing heat exchanger
- Direct vent sealed combustion
- Approved for room and closet installations
