resideo T4 PRO Series TH4210U-PERFORM Programmable Thermostat, 20 to 30 V
- Manufacturer: Resideo Technologies Inc
- Brand Name: resideo
- Part#: HONTH4210U2002
- MPN: TH4210U-PERFORM
- UPC: 085267187336
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at All Branches
-
Price:
The T series programmable thermostat streamlines everything from product selection and installation to customer service and support. With a standard footprint and simple interface, the T series will enhance the entire thermostat experience for you and your customers alike.
resideo Programmable Thermostat, T4 PRO Series, 20 to 30 V, 50/60 Hz Frequency, Programmability: 5-1-1 days Programmable, 5-2 days Programmable, 7 days Programmable or Non-Programmable, Changeover: Auto, Manual, Battery, Hardwired Power Source, 1 Heat/1 Cool Conventional, 2 Heat/1 Cool Heat Pump Stages, Switch Position: Heat-Off-Cool-Auto-Emergency Heat (System), Auto-On Fan, Relay Switch, Medium, Soft Key Control with LED Backlight Display, +/-1 deg F Differential, 40 to 90 deg F Heat, 50 to 99 deg F Cool Settings, 37 to 102 deg F, 5 to 90% RH Non-Condensing Humidity, 1 deg F Accuracy, Wall Mounting, Cool Current: 0.02 to 1 A, Terminal Designation: C, G, K, L, O/B, R, RC, W, Y, Fan Current: 0.02 to 0.05 A, Heat Current: 0.02 to 1 A, 1 VA, White, Dimensions: 4-1/16 in H x 4-1/16 in W x 1-3/32 in D
| Accuracy | : | 1 deg F |
| Changeover | : | Auto, Manual |
| Color | : | White |
| Cool Current | : | 0.02 to 1 A |
| Differential Temperature | : | +/-1 deg F |
| Dimensions | : | 4-1/16 in H x 4-1/16 in W x 1-3/32 in D |
| Display Type | : | Medium, Soft Key Control with LED Backlight |
| Fan Current | : | 0.02 to 0.05 A |
| Frequency Rating | : | 50/60 Hz |
| Heat Current | : | 0.02 to 1 A |
| Humidity Rating | : | 5 to 90% RH Non-Condensing |
| Mounting Type | : | Wall |
| Power Source | : | Battery, Hardwired |
| Programmability | : | 5-1-1 days Programmable, 5-2 days Programmable, 7 days Programmable or Non-Programmable |
| Series | : | T4 PRO Series |
| Stages | : | 1 Heat/1 Cool Conventional, 2 Heat/1 Cool Heat Pump |
| Switch Position | : | Heat-Off-Cool-Auto-Emergency Heat (System), Auto-On Fan |
| Switch Type | : | Relay |
| Temperature Rating | : | 37 to 102 deg F |
| Temperature Settings | : | 40 to 90 deg F Heat, 50 to 99 deg F Cool |
| Terminal Designation | : | C, G, K, L, O/B, R, RC, W, Y |
| VA Rating | : | 1 VA |
| Voltage Rating | : | 20 to 30 V |
- Uses the UWP-mounting system that's standard across all T series thermostats
- Easy upsell to a connected Lyric™ T6 Pro Wi-Fi when your customer is ready for Wi-Fi (C-wire required)
- Simple pushbutton functionality
- Filter change reminders
