PRO1® T700 Series T701 Thermostat, 18 to 30 VAC, 1 to 1.5 A, (2) AA Alkaline Battery, 1 Heat/1 Cool
- Manufacturer: Pro1 IAQ
- Brand Name: PRO1®
- Part#: PROT701
- MPN: T701
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at All Branches
-
Price:
PRO1® Thermostat, T700 Series, 18 to 30 VAC, 1 to 1.5 A, 50/60 Hz Frequency, 1 Heat/1 Cool Stages, 4 sq-in Blue Backlight Display, 0.2 to 2 deg F Heating and Cooling Differential, 44 to 90 deg F Settings, 32 to 105 deg F Ambient, 90% Non-Condensing Humidity, (2) AA Alkaline Battery, +/-1 deg F Accuracy, Battery, Hardwired Power Source, Horizontal/Junction Box Mounting, Dimensions: 4.4 in H x 4.7 in W x 1.1 in D
| Accuracy | : | +/-1 deg F |
| Amperage Rating | : | 1 to 1.5 A |
| Battery Type | : | (2) AA Alkaline |
| Differential Temperature | : | 0.2 to 2 deg F Heating and Cooling |
| Dimensions | : | 4.4 in H x 4.7 in W x 1.1 in D |
| Display Type | : | 4 sq-in Blue Backlight |
| Frequency Rating | : | 50/60 Hz |
| Humidity Rating | : | 90% Non-Condensing |
| Mounting Type | : | Horizontal/Junction Box |
| Power Source | : | Battery, Hardwired |
| Series | : | T700 Series |
| Stages | : | 1 Heat/1 Cool |
| Temperature Rating | : | 32 to 105 deg F Ambient |
| Temperature Settings | : | 44 to 90 deg F |
| Voltage Rating | : | 18 to 30 VAC |
- Glow in the dark light button
- Easy access battery compartment
- Separate heating and cooling swing (cycle rate) adjustments
- Room temperature calibration adjustments
- 5 min compressor delay protection (selectable on or off)
- Simple private label badge system
- Easy wire color-coded terminal blocks
- Universal sub-base
- Mounts on wall or junction box
- 41 - 95 deg F display
- Permanent memory back-up
