LG LVN360HV4 Single-Zone Vertical Air Handler Unit, 208-230 V, 40 A, 44000 Btu/hr, 47000 Btu/hr BTU, 1 ph
- Manufacturer: LG Electronics
- Brand Name: LG
- Part#: LGLVN360HV4
- MPN: LVN360HV4
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at All Branches
-
Price:
LG Single-Zone Vertical Air Handler Unit, 208-230 V, 40 A, 60 Hz, 1 ph, 3 Fan Speeds, 44000 Btu/hr, 47000 Btu/hr, CFM Rating: 1000 cfm, 1100 cfm, 900 cfm, 12.5 EER, 18 SEER, HSPF: 10, R-410A, Brushless Digitally Controlled, Direct Drive, 43 dBA, 44 dBA, 45 dBA, 54-11/32 in Overall Length, 37-13/32 in Overall Width, 13 in Overall Height
| Amperage Rating | : | 40 A |
| BTU Rating | : | 44000 Btu/hr, 47000 Btu/hr |
| CFM Rating | : | 1000 cfm, 1100 cfm, 900 cfm |
| Drive Type | : | Brushless Digitally Controlled, Direct |
| EER Rating | : | 12.5 |
| Frequency Rating | : | 60 Hz |
| HSPF Rating | : | 10 |
| Number of Fan Speeds | : | 3 |
| Overall Height | : | 13 in |
| Overall Length | : | 54-11/32 in |
| Overall Width | : | 37-13/32 in |
| Phase | : | 1 ph |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 18 |
| Sound Level | : | 43 dBA, 44 dBA, 45 dBA |
| Voltage Rating | : | 208-230 V |
- ESP control
- Hot start
- Auto restart
- Group control
- Timer on/off
- Sleep mode
- Built-in dry contact
- Inverter (variable speed fan)
Specification Sheet
