LG KNMLB361A Multi-Position Air Handler Ducted Indoor Unit, 1050 cfm, 208-230 V, 3.4 A, 60 Hz, 1 ph
- Manufacturer: LG Electronics
- Brand Name: LG
- Part#: LGKNMLB361A
- MPN: KNMLB361A
- UPC: 195174101186
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at All Branches
-
Price:
LG Multi-Position Air Handler Ducted Indoor Unit, 36000 Btu/hr Cooling Capacity, 40000 Btu/hr Heating, 208-230 V, 3.4 A, 60 Hz, 1 ph Phase, 1050 cfm, Horizontal Left, Horizontal Right, Vertical Downflow, Vertical Upflow, FPT Connection, R-32 Refrigerant, 40 dBA Sound Level, 18 FPI Coil, 3/4 in Connection, 3/8 in Liquid Line, 5/8 in Suction Line, 20 x 20 x 1 in Filter, Brushless Digitally Controlled Motor, 1 in-WG, Ceiling, Concealed Mounting, Metal, Finish: High Gloss Baked Enamel, 57 to 77 deg F Cooling, 59 to 81 deg F Heating, 55-3/16 in H x 21 in W x 21-3/8 in D, Additional Information: Multi-Zone
| Additional Information | : | Multi-Zone |
| Amperage Rating | : | 3.4 A |
| CFM Rating | : | 1050 cfm |
| Coil Rating | : | 18 FPI |
| Configuration | : | Horizontal Left, Horizontal Right, Vertical Downflow, Vertical Upflow |
| Connection Size | : | 3/4 in |
| Connection Type | : | FPT |
| Cooling Capacity | : | 36000 Btu/hr |
| Dimensions | : | 55-3/16 in H x 21 in W x 21-3/8 in D |
| Filter Size | : | 20 x 20 x 1 in |
| Finish | : | High Gloss Baked Enamel |
| Frequency Rating | : | 60 Hz |
| Heating Capacity | : | 40000 Btu/hr |
| Liquid Line Size | : | 3/8 in |
| Material | : | Metal |
| Motor Type | : | Brushless Digitally Controlled |
| Mounting Type | : | Ceiling, Concealed |
| Phase | : | 1 ph |
| Pressure Rating | : | 1 in-WG |
| Refrigerant Type | : | R-32 |
| Sound Level | : | 40 dBA |
| Suction Line Size | : | 5/8 in |
| Temperature Rating | : | 57 to 77 deg F Cooling, 59 to 81 deg F Heating |
| Voltage Rating | : | 208-230 V |
- Access Panel for Field Supplied Air Filter
- Inverter (variable speed fan)
- Hot start
- Self diagnosis
- Soft dry operation
- Auto operation
- Auto restart
- Sleep mode
- Timer (on/off/weekly)
- R32 leak detection sensor
- Integrated dry contact for 3rd party thermostat
