Hart & Cooley® CBPR8 Curved-Blade Perforated Return Grille With 8 in Neck, 4-Way Deflection, 4-7/8 in L, 23-3/4 in W
- Manufacturer: Duravent Group
- Brand Name: Hart & Cooley®
- Part#: HARCBPR8
- MPN: CBPR8
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at All Branches
-
Price:
Hart & Cooley® Curved-Blade Perforated Return Grille, Series: CBPR Series, 4-Way Deflection, CFM Rating: 420 cfm, 7-7/8 in Duct, 4-7/8 in Length, 23-3/4 in Width, 23-3/4 in Height, Steel, Bright White Enamel, Additional Information: Square Shape, For Use With 2 x 2 ft T-Bar Ceiling Systems
| Additional Information | : | Square Shape, For Use With 2 x 2 ft T-Bar Ceiling Systems |
| CFM Rating | : | 420 cfm |
| Deflection Type | : | 4-Way |
| Duct Size | : | 7-7/8 in |
| Finish | : | Bright White Enamel |
| Height | : | 23-3/4 in |
| Length | : | 4-7/8 in |
| Material | : | Steel |
| Series | : | CBPR Series |
| Width | : | 23-3/4 in |
- Removable, hinged face allows for easy access to air pattern control core
- Individually adjustable pattern deflectors factory set at 4-way deflection, can be field-adjusted for 1, 2, 3-way air patterns
- Unique 2 in high collar permits easy flex connections
- Accepts 3800 Series butterfly damper (order separately)
Full Engineering Drawing
