Field Controls Fan-in-a-Can® CAS-3 Oil System, 120 V, 2600 rpm Speed, 160 cfm, 325 cfm
- Manufacturer: Field Controls, LLC
- Brand Name: Field Controls
- Part#: FIECAS3
- MPN: CAS-3
- UPC: 090747333509
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at All Branches
-
Price:
Field Controls Fan-in-a-Can® Oil System, 120 V, 2600 rpm, 160 cfm, 325 cfm Flow Rate, 6 in ID x 10-1/4 in OD Housing Diameter, 68 dB at 36 in Sound Level, Stainless Steel, 12-1/2 in H
| Dimensions | : | 12-1/2 in H |
| Flow Rate | : | 160 cfm, 325 cfm |
| Housing Diameter | : | 6 in ID x 10-1/4 in OD |
| Material | : | Stainless Steel |
| Sound Level | : | 68 dB at 36 in |
| Speed Rating | : | 2600 rpm |
| Voltage Rating | : | 120 V |
- According to NFPA 54 and NFPA 31, an engineered system CAS-3 may be used to overcome the lack of air in a confined space
- Each is designed for optimum safety and includes a proving device that won't allow the burner to engage without the Fan-in-a-Can® operating
- Multiple units or additional controls are required for multiple appliance installations, each is equipped with a two-speed control for enhanced versatility
- The CAS-3 model are designed to provide combustion air for appliances when direct connection to the burner is not possible (when the appliance is located in a confined space)
Instruction/Installation Manual
