Duro Dyne® BTL500 Gasket Roll, 25 ft L, 5/8 in W, 3/16 in Thick, Butyl/Synthetic Polymer, Gray

  • Manufacturer: NSi Industries
  • Brand Name: Duro Dyne®
  • Part#: DURBTL500
  • MPN: BTL500
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at All Branches

BTL500 Butyl Gaskets offer an easy-to-use sealant to provide a moisture and vapor-tight seal to prohibit water and dust from any connection at any atmospheric pressure. Butyl gasket is used in tape and bead form to seal transverse duct connections systems helping to provide a moisture and air tight seal. This tighter seal also helps reduce energy waste and noise.

Duro Dyne® Gasket Roll, Model: BTL500, 25 ft Length, 5/8 in Width, 3/16 in Thickness, 0 to 100 deg F, Butyl/Synthetic Polymer, Gray, Additional Information: 1.45 g/cc Specific Gravity, 10 to 12 psi Adhesive Tensile Strength

Additional Information      :      1.45 g/cc Specific Gravity, 10 to 12 psi Adhesive Tensile Strength
Color      :      Gray
Length      :      25 ft
Material      :      Butyl/Synthetic Polymer
Model      :      BTL500
Temperature Rating      :      0 to 100 deg F
Thickness      :      3/16 in
Width      :      5/8 in
  • Butyl gaskets offer an easy-to-use sealant to provide a moisture and vapor-tight seal to prohibit water and dust from any connection at any atmospheric pressure
  • Butyl gasket is a permanently soft caulking compound with a high percentage of virgin butyl rubber
  • It will adhere to most dry, clean surfaces such as steel, aluminum, plastics, wood and concrete and can withstand movement without cracking
  • Non-corrosive
  • Flexible to -20 deg F
  • Provides a moisture and vapor tight seal
  • Excellent resistance to water, alcohol, mild acids and mild bases
  • 5 flame, 5 smoke eveloped rating
  • 1 year shelf life
  • Paintable
