Duro Dyne® 10003 Flexible Duct Connector, Fiberglass, Neoprene-Coated, 24 ga, Black
- Manufacturer: NSi Industries
- Brand Name: Duro Dyne®
- Part#: DURMFN333
- MPN: 10003
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at All Branches
-
Price:
All air duct installations for heating, cooling or ventilation are attached to mechanical equipment containing a fan or blower. Vibrations, noises and rattles resulting from operation of the fan or blower are transmitted into the metal ducts which can carry noise throughout the system. In order to isolate the vibration and noise to the source, an airtight flexible joint, consisting of a fabric which is attached to sheet metal on both edges, must be inserted between the equipment and the ductwork. This vibration isolator is called a flexible duct connector.
Duro Dyne® Flexible Duct Connector, 12 lb Tear Strength, 500 lb, 450 lb Tensile Strength, 24 ga Gauge, Fiberglass, Finish: Neoprene-Coated, Black, 100 ft Length, -40 to 200 deg F
| Color | : | Black |
| Connection Type | : | Grip Loc |
| Finish | : | Neoprene-Coated |
| Gauge | : | 24 ga |
| Length | : | 100 ft |
| Material | : | Fiberglass |
| Tear Strength | : | 12 lb |
| Temperature Rating | : | -40 to 200 deg F |
| Tensile Strength | : | 500 lb, 450 lb lb |
- Extremely-resistant to alkalies and gasoline
- Excellent on systems exposed to toxic fumes
- Good general purpose fabric
- Unaffected by mildew
- Neoprene coating
- 30 oz/sq-yd weight
Catalog
