ACUDOR FW-50501616 Fire-Rated Insulated Access Door, 16 in W Door, 16 in H Door, Latch Locking
- Manufacturer: Nelson Industrial Inc
- Brand Name: ACUDOR
- Part#: ACUFW50501616
- MPN: FW-50501616
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at All Branches
-
Price:
The ACUDOR FW-5050 is a fire-rated, insulated, metal access door. The FW-5050 is designed for walls and ceilings when temperature rise or heat transmission is a factor.
ACUDOR Fire-Rated Insulated Access Door, 16 in Door Width, 16 in Door Height, 15.78 in Opening Width, 15.78 in Opening Height, 20 ga, Latch Locking, Concealed Hinge, Additional Information: Single-Latch
| Additional Information | : | Single-Latch |
| Door Height | : | 16 in |
| Door Width | : | 16 in |
| Gauge | : | 20 ga |
| Hinge Type | : | Concealed |
| Locking Type | : | Latch |
| Opening Height | : | 15.78 in |
| Opening Width | : | 15.78 in |
- Walls - UL 1-1/2 hr "B" label, ULC 2 hr "B" label, max size 36 x 48
- Ceilings - warnock hersey international 3 hr rated in a non-combustible ceiling, 1 hr rated in a combustible ceiling, max size 24 x 36
- Inside latch release
- 20 ga door panel, filled with 2 in thick fire-rated insulation
- Door panel filled with 2 in thick fire-rated insulation
- Insulated door panel
- Self-closing
- Self-latching
